DOTSIGHT

ACTUS High Precision Red dot sight

ACTUS® DOTSIGHT
ACTUS® DOTSIGHT

CHARACTERISTICS



ACTUS dot-sight is an optical equipment with excellent performance and durability as the " equipment selected as Warrior Platform" of the Republic of Korea Army (ROKA).

It is a MIL-SPEC equipment that meets military requirements such as extreme high and low temperature tests, impact tests, waterproofing, and fluid contamination. It protects the life and safety of users between missions, and helps to shoot quickly and accurately.

AL7075-T6 material used

Using 75 material with high tensile strength and hardness,
it has excellent durability against external impact.

Wedge-type doublet lenses applied

By applying our own patented technology lens,
 the occurrence of parallax was minimized and keystone distortion was alleviated.

scope

3X high-performance magnifying glass operation function

The ACTUS dot sight was designed to be operated with 3X high-performance magnifying glass.
 You can quickly and easily switch from 1x to 3x when operating with a 3X high-performance magnifying glass.

1x magnification dot sight

1x magnification dot sight / 3x magnification high-performance magnifying glass

ACTUS® DOTSIGHT

CHARACTERISTICS






CORE-1
CORE-2
PARA-1
POWER
SOURCE
 1X AAA battery
3V Lithium Battery CR2032
1X CR2032 battery
BATTERY
LIFE
65,000hrs AT LV7
30,000hrs AT LV6
30,000hrs AT LV6
13,000hrs AT LV7
180hrs AT LV 11(MAX)
OBJECTIVE
LENS
20mm
20mm
18mm
MAGNIFI
CATION
1X
1X
1X
DOT SIZE
2 MOA
2 MOA
2 MOA
BRIGHTNESS
SETTINGS
OFF /LB#1 1~4(NIGHT), 5~11(DAY)
OFF /LB#1 1~4(NIGHT), 5~11(DAY)
OFF /LB#1 1~4(NIGHT), 5~11(DAY)
ADJUSTMENT
RANGE
±40 MOA U/D ±40MOA L/R 0.5/1 CLICK
±40 MOA U/D ±40MOA L/R 0.5/1 CLICK
±40 MOA U/D ±40MOA L/R 0.5/1 CLICK
OPTICAL
COATING
7075-T6 ALUMINUM (FORGED)
7075-T6 ALUMINUM (FORGED)
7075-T6 ALUMINUM (FORGED)
SIZE
98.2mmX49.5mmX66.2mm
69.0mmX46.3mmX79mm
45.3mmX41.3mmX75.5mm
WEIGHT
223.0g
194g
172.2g
RETICLE
COLORS
RED
RED
RED
ACTUS® DOTSIGHT
